CABLE TYPE |
INNER |
PE DIELDCTRIC
CORE DIAMETER |
PVC JACKET
CORE DIAMETER |
CHARCTERISTIC
IMPEDANCE(10MHz) |
ANNEALED COPPER |
DIAMETER |
1.5C-2V |
1/0.26 |
0.26 |
1.6 |
2.9 |
75 ± 3 |
2.5C-2C |
1/0.4 |
0.4 |
2.4 |
4 |
75 ± 3 |
3C-2V |
1/0.5 |
0.5 |
3.1 |
5.4 |
75 ± 3 |
5C-2V |
I/0.8 |
0.8 |
4.9 |
7.4 |
75 ± 3 |
5C-2W |
1/0.18 |
0.8 |
4.9 |
8.3 |
75 ± 3 |
7C-2V |
7/0.4 |
1.2 |
7.3 |
10.4 |
75 ± 3 |
10C-2V |
7/0.5 |
1.5 |
9.4 |
13 |
75 ± 3 |
10C-2W |
1/2.9 |
1.5 |
9.2 |
14.3 |
75 ± 3 |
20C-2V |
7/0.32 |
2.9 |
19 |
24.1 |
75 ± 3 |
3D-2V |
112.9 |
0.96 |
3 |
5.3 |
5O ± 2 |
8D-2V |
1/1.29 |
2.4 |
7.8 |
11.1 |
5O ± 2 |
10D-2V |
1/0.724 |
2.4 |
20.8 |
13.1 |
5O ± 2 |
RG-5/U |
1/0.724 |
4.7 |
4.7 |
8.4 |
52.5 ± 2 |
RG-6/U |
1/0.914 |
4.7 |
4.7 |
8.4 |
76 ± 3 |
RG-6A-U |
7/0.724 |
4.7 |
4.7 |
8.4 |
75 ± 3 |
RG-7/U |
7/0.724 |
6.35 |
6.35 |
9.4 |
97.5 ± 7.5 |
RG-8/U |
7/0.724 |
7.24 |
7.24 |
10.3 |
52 ± 2 |
RG-8A-U |
710.724 |
7.24 |
7.24 |
10.3 |
52 ± 2 |
RG-10/U |
710.724 |
7.24 |
7.24 |
10.3 |
52 ± 2 |
RG-11/U |
7/0,404 |
7.24 |
7.24 |
10.3 |
75 ± 3 |
RG-11A/U |
7/0,404 |
7.24 |
7.24 |
10.3 |
75 ± 3 |
RG-12A/U |
710.404 |
724 |
7.24 |
10.3 |
75 ± 3 |
RG-12A/U |
7/0.404 |
7.24 |
7.24 |
10.3 |
75 ± 3 |
RG-13/U |
7/0.404 |
7.11 |
7.11 |
10,7 |
74 ± 3 |
RG-14/U |
1/2.59 |
9.4 |
9.4 |
13.8 |
52 ± 2 |
RG-15/U |
1/1.45 |
9.4 |
9.4 |
13.8 |
76 ± 3 |
RG.17/U |
1/4.78 |
17.3 |
17,3 |
22.1 |
52 ± 2 |
RG-17A/U |
1/4.78 |
17.3 |
17.3 |
22.1 |
52 ± 2 |
RG-18/U |
1/4.78 |
17.3 |
17.3 |
22.1 |
52 ± 2 |
RG-19/U |
1/6.35 |
23.1 |
23.1 |
28.5 |
52 ± 2 |
RG-20/U |
1/6.35 |
23.1 |
23,1 |
28.5 |
95 ± 5 |
RG-22/U |
7/0.386×2C |
7.24 |
7,24 |
10.3 |
95 ± 5 |
RG-22A/U |
7/0.386 ×2C |
7.24 |
7.24 |
10.7 |
95 ± 5 |
RG-22B/U |
7/0.386 ×2C |
7.24 |
7.24 |
10.7 |
125 ± 5 |
RG-23/U |
7/0.724 ×2C |
9.65 |
9.65 |
16.5 × 24.0 |
125 ± 5 |
RG-24/U |
7/0.724 ×2C |
9.65 |
9.65 |
16.5 × 24.0 |
125 ± 5 |
RG-29/U |
110.813 |
0.813 |
2,95 |
4.7 |
53.5 ± 2.5 |
RG-34/U |
7/0.724 |
1 |
11 6 |
15.9 |
71 ± 3 |
RG-35/U |
1/2.90 |
2.9 |
17.3 |
22.1 |
71 ± 3 |
RG-55/U |
1/0.813 |
0.813 |
2.9 |
5 |
53.5 ± 2.5 |
RG-57/U |
7/0.724×2C |
1 |
12 |
15.9 |
9.5 ± 5 |
RC-58/U |
1/0.813 |
0.813 |
2.95 |
4.95 |
53.5 ± 2.5 |
RG-58A/U |
19/0.18 |
1 |
2.95 |
4.95 |
5O ± 2 |
RG-58C/U |
19/0.18 |
1 |
2.95 |
4.95 |
5O ± 2 |
RG-59/U |
1/0.643 |
0.643 |
3.71 |
6.15 |
73 ± 2 |
RG-59A/U |
1/0643 |
0.643 |
3.71 |
6.15 |
73 ± 2 |
|
|
| |
